Automatic Timed Electronic Auto Drain Valve For Air Compressor Water Tank 110V
$ 18.44
Description
Automatic Timed Electronic Auto Drain Valve For Air Compressor Water Tank 110V Electronic Drain Valve For Air Compressor Water Tank 1/2'' Auto Automatic Timed Specification: Product Name: Timing Drain Valve Voltage: AC110V 50Hz Voltage Range: 10% Time Interval ( OFF ): 0.5--45 minutes (adjustable) Discharge Time ( ON ): 0.5--10 seconds (adjustable) Manual Test Button: Yes( micro switch) The Current Consumption: Max 4mA Shell Material: Flame retardant ABS plastic Electrical Connection: DIN43650A Indicator Lamp: LED indicating power ON / OFF Type: two-way direct-acting valve Flow Aperture: 5 mm Insulation Class: H In / Out Port Size: 1/2" Maximum Working Pressure: 1.6Mpa Maximum Temperature: 90 C Valve Material: Forging brass Installation: 1. Clean the compressed air system before installing 2. Attention to the direction of the arrow when the valve body; outlet do not use the verdana of the hose does not verdana 3. The supply voltage must be the same as the drain valve voltage; when using DC, the positive pole must be connected to the connector "1" 4. The factory has been connected to the cable drain valve, fade for the fire line L, blue for the zero line N, yellow and green color for the safe ground GND 5. Always tighten the long screws on the verdana box to prevent the water from burning Timer setting: Left knob to set the discharge time, the right knob to set the interval time; the first discharge time of 2s, the interval time is 20min, and then need to be further adjusted Package Include: 1x Drain Valve Payment Delivery details Terms of sales About us Contact us Payment We accept ebay payment 。 Fees such as import duties, taxes are not included in the item price or shipping costs. These charges are the buyer's responsibility. Delivery details Shipping: 2-9 working days to: USA Terms of sales We maintain high standards of excellence and strive for hundred percent customer satisfaction. Feedback is very important to us. We hope that you contact us immediately before you give neutral or negative feedback, so that we can address your concerns. It is impossible to address issues if we do not know about them! About us Your satis faction is our ultimate goal. We work hard to earn your trust and future business. Our certified technicians have tested each item before shipping. The unit comes with 1 year limited warranty on all manufacturing defects. a) If you receive a defective item, you may return it or ask for a discount. Please contact us within 14 days after you receive the package. b) What you returned must be intact and in its original packaging as re? u. Customer is responsible for shipping costs of the returned item. c) We will cover the cost of shipping back t with the shipping rate indicated in the registration page. We will send you a new unit or refund the full payment you paid. Thank you. Contact us Business Hour Business Hour: Monday To Friday: 8:30 AM to 5:00 PM (Beijing China time) Due to time zones, our reply to your questions may not be immediately. But within above working time, we will reply your email within 24 hours. If it's non-workdays, please kindly be patient and wait till Monday. Please contact us with ebay message. Please feel free to contact us if you have any questions. Monday To Friday: 8:30 AM to 5:00 PM (Beijing China time) Due to time zones, our reply to your questions may not be immediately. But within above working time, we will reply your email within 24 hours. If it's non-workdays, please kindly be patient and wait till Monday. Please contact us with ebay message. Please feel free to contact us if you have any questions.
