US Motors - Nidec 3274 0.143 HP, oil burner Split Phase and Capacitor Start

$ 23.76

Seller Notes: “Was used as a demo on a sales floor only” Enclosure: Semi-Enclosed Model: K041AAT1016013J Rotation: CCWSE Voltage: 115 Product Type: OEM Replacement Motor Phase: Single Phase Horsepower: 1/7 MPN: 3274 Brand: Nidec Electrical Type: PSC RPM (Range): 2500-3700 AC Phase: Single Phase

Description

Item # 09 replaces A.O. Smith/MagneTek/Century/Universal/MARATHON OBK6002 or BECKETT 21805U or 04777 or 98022S or S89-254 Direct Replacement Oil Burner Motor for Beckett, Carlin, Ducane, Wayne 1/7 HP, 3450 RPM, 115 Volts, 48M Frame 1/7 hp 3450 RPM 1-Speed 115V; 1.7 amps, 60HZ Shaft 1/2" x 2.0" Rotation: CCW shaft end 48M Frame 6.25" Diameter Ball Bearings Flange Mount (2 screws 6-3/4" apart) 20" Power Leads PSC Motor - Preinstalled Capacitor Automatic Overload Protection; Class F Insulation; 40C Ambient Temperature 1 Year Manufacture Warranty Applications: Domestic high and low pressure oil burners and other applications where 48M flange mounting is required. This motor is open shaft side for ventilation. All mounting dimensions such as location of ears, diameter of rabbet fit and shaft size are in accordance with NEMA standards. Suggested replacement for: Beckett 21805U, AF/AFG/NX Series Burners Century OBK6 002V1 Nidec/US Motor K041AAT1016013J, K41GWAAT-1016 Dayton 3AAC3
