Schneider Electric 3-Way PopTop Zone Valve (120V)Actuator AG13B020.
$ 39.6
Description
Schneider Electric 3-Way PopTop Zone Valve (120V)Actuator AG13B020.. OEM PopTop replacement actuator from Schneider Electric (Erie), designed for 3‑way mixing/diverting valves • Input voltage: 110–120 VAC, synchronous motor drive with spring-return for fail-safe operation   • Control: 2‑position (on/off) with manual override lever • Normally‑closed design; mounting is quick and tool-free—“PopTop” snap-on design  • Auxiliary SPDT contacts rated 24–240 VAC (min 101 mA, max 5 A)  • Power draw: ~6.5 W (7.5 VA)  • Operating fluid temp: 32–200 °F; ambient max 104 °F  • UL-listed, NEMA 1 housing; actuator weight approx. 1 lb  • Ideal for PopTop series 3‑way valve bodies (e.g., VT3213) with ½″ sweat or NPT connections, up to 4.0 Cv OEM PopTop replacement actuator from Schneider Electric (Erie), designed for 3‑way mixing/diverting valves • Input voltage: 110–120 VAC, synchronous motor drive with spring-return for fail-safe operation   • Control: 2‑position (on/off) with manual override lever • Normally‑closed design; mounting is quick and tool-free—“PopTop” snap-on design  • Auxiliary SPDT contacts rated 24–240 VAC (min 101 mA, max 5 A)  • Power draw: ~6.5 W (7.5 VA)  • Operating fluid temp: 32–200 °F; ambient max 104 °F  • UL-listed, NEMA 1 housing; actuator weight approx. 1 lb  • Ideal for PopTop series 3‑way valve bodies (e.g., VT3213) with ½″ sweat or NPT connections, up to 4.0 Cv
