HD1920*1200 Computer Laptop TV Repair Tool LCD/LED Test Tool Panel Tester B
$ 51.56
Description
Product Description Features: 1. Built-in 55 kinds of programs, 12 test pictures 2. Support LED and LCD panel 3. Support to 7-84'' panel, resolution : HD1920 * 1200 4. Short circuit protection 5. Package includes : 1x panel tester; 1x 1/2/4 lamp backlight inverter driver board; 14x Lvds cables Important: 1, Have English manual,so that you can use it properly. 2, Do not try to disassemble or open it . After display show ''88'', itwill be automatically locked, can not be used and we can not change itfor you. 3, Powered by 12V 4A adapter(not included). Color of the tester: Blue Updates: 1. Update to 55 programes,12 test pictures 2. Short circuit protection when screen shows : "A1"- panel cable short circuit "A2"- 12v backlight Short circuit "A3"- 5v backlight Short circuit 3. VGA Input and Output 4. Single Chip Computer, support Panel B+ Features: 1. More convenient, durable, convenient, high efficiency and practical. 2. Support New 5V LED screen backlight , VGA interface 3. Support 55 kinds of programs, 12 tester pictures 4. Support for LCD and LED 5. Support HD 1920 * 1200 6. Support for 7-84 inch 7. Screen tester and inverter tester 8. Short circuit protection How to set up tester to test LCD Screen: 1, Identify know the part number of the LCD Panel 2, Choose a correct LVDS cable and setting according to the panel 3, Apply setting to Tester (Right resolution and screen voltage) 4, Connect LCD panel LVDS cable between Tester and LCD Panel 5, Connect LCD screen's back light to Tester 6, Apply Input Signal to VGA 7, Connect 12V DC to Tester and Turn it on Detailed information about the LVDS cables: 1,fix 30pin single 8 2,fix 30pin single 6 3,fix 30pin double 8 4,df 14 single 8 5,df 14 single 6 6,df 14 double 6 7,fix 10.1'' cable 8,led 15.6'' cable 9,fix 20pin single 6 10,fix 20pin single 8 11, 51146 single 6 Totally 14 pcs LVDS cables Package Contents: 1* panel tester 14* LVDS cable 1* 12V Power 1* single lamp inverter If you have any doubts or uncertainty about this item, contact us with no hesitation, we are always here and will solve your problems. Thanks and wish you a nice day! About Us We dedicated to provide excellent products and services for all customers on ebay. hope we all can have a nice experiences on eBay. Payment We accept all verified payment through PAYPAL payment. Shipping Usually, Item will be shipped within 1-2 working day after full payment is received. Normally, you will receive the item in 5-7 days. Please contact us if you don’t receive the items after 10 working days after the payment If you have any questions about shipping, please feel free to contact us. Returns Always believe we can solve problems by communication if it comes to any problems about products or any others. If it comes to a return, the products must be intact and as original when you received, and should be within 30 days after you received it. Contact Us Work time: 9:00 AM to 18:00 PM Beijing Time You can contact us at anytime you want, we will reply all messages at the first time. powered by
