Electric Brushless DC Motor 48-Volt 2000-Watt Electric Motor 4300 RPM High Speed

$ 39.6

Shaft Diameter: Does Not Apply UPC: 840281529407 Working Temperature: < 120 °C / 248 ℉ Current Type: DC Dimensions(L x W x H): 6.7 x 4.2 x 4.3'' / 169 x 107 x 110 mm No-load Current: ≤ 3.8A Mounting Type: Base-Mounted MPN: ZLDJWSD2K48V102SNV0 DC Stator/Winding Type: Does Not Apply Rated Speed: 4300 RPM Service Factor: Does Not Apply Mount Bracket Size: 2.2 x 4'' / 56 x 102 mm Rated Current: 34A Under Voltage Protection Voltage: 41±0.5V Horsepower: 2.67HP Reversible/Non-Reversible: Reversible Shaft Type: Keyed AC Motor Type: Does Not Apply Special Motor Construction: Does Not Apply Shaft Length: 5.28'' / 134 mm Sprocket: T8F-11T Nominal Rated Input Voltage: 48 V Controller ​Model: BY15WF02-A Brand: VEVOR Phase Degree: 120° Maximum Speed: 5400 RPM Controller ​Current: 34A gtin13: 840281529407 Enclosure Type: Does Not Apply Peak Efficiency: ≥ 85% Conversion Efficiency: 90% NEMA Frame Suffix: Does Not Apply Base RPM: 4300 RPM Net Weight: 10.36 lbs / 4.7 kg Rated Torque: 4.2 N.m / 594.77 oz.in AC Frequency Rating: Does Not Apply Maximum Current: 42A Output Power: 2000W IEC Frame Size: Does Not Apply Actual Rated Input Voltage: 48V DC AC Phase: Does Not Apply Input Voltage: 48V DC Rated Load (HP): Does Not Apply Model: MY1020D

Description

VEVOR offers a robust 48V DC electric brushless motor with a powerful 2.67HP output and a maximum speed of 5400 RPM, ensuring high efficiency and performance. The motor features a durable keyed shaft with a length of 5.28 inches and a no-load current of just 3.8A, promising smooth operation and reduced energy consumption. Its rated torque is 4.2 N.m, and it includes a T8F-11T sprocket for easy setup. The motor is designed for versatility with a reversible feature and a working temperature limit of 248 ℉, making it suitable for a wide range of applications. The included BY15WF02-A controller delivers a current of 34A, providing reliable control and protection. Its compact size, 6.7 x 4.2 x 4.3 inches, and lightweight design, at 10.36 lbs, allow for easy integration into various systems.
