AUTO BODY FRAME MACHINE POWER TEAM PA6 OTC 4020 FOOT PEDAL PUMP USA BUILT
$ 251.86
Description
THE pedal pump that started it all. OEM equipment on many auto body frame machines and other tools. Longest lasting, hardest working and most copied pump on the planet. Buy the best, buy American! SOLD AND MARKETED AS OTC MODEL 4200 AS WELL Power Team SPX Air Hydraulic Pump 6 CU. IN/MIN 10;000 PSI PA6 FEATURES: The single-speed pumps designed to drive single-acting cylinders or tools are compact; lightweight; and portable. Operate with 40-100 psi standard shop air pressure at the pump. The air over hydraulic system uses this lower air pressure to builds hydraulic pressure to 10;000 PSI. Internal relief valves protect circuit components; air inlet filter protects motor. All metal air motor; ductile iron pump. Serviceable pump motor is not a throw away"; providing economical repair. Foot peddle pump or treadle pump allows user to control the hydraulic pressure and flow for the system. The power unit of choice for major manufacturers of auto body; frame straighteners and other equipment. Air Supply Required (psi) 90-120 Reservoir Capacity (Cu. In.) 105 Reservoir Usable (Cu. In.) 98 Oil Port (In.) 3 Maximum Pressure (psi) 10;000 Typical Flow at Max psi 6 in³/min Outlet Port Size 3/8 NPTF
