2 HP 3 Phase Electric Motor 1800 RPM 56C Frame TEFC 230/460V Premium Efficiency
$ 83.38
Description
Feature: 2 horsepower, 3 phase electric motor. Designs and manufactures motors with quality and reliability in mind. This motor features Class F insulation, fan cooling, a 1.15 service factor, is a premium efficiency motor and rated for inverter duty. Also suitable for 50 hz operation with a 1.0 service factor. All the worldwide TEFC enclosed 56 frame fractional 3 phase motors have a removable base, with a C-face, and shaft slinger to keep moisture and contaminants from the end of the drive-end bearing for longevity. Specification: AC Frequency Rating: 60 Hz Base RPM: 1800 Horsepower (HP): 2HP AC Phase(PH): 3 Phase Frame: 56C Enclosure Type: TEFC Current: AC Voltage: 208-230/460 Volt Full Load Amps: 5.92/2.96A (5.56/2.78A) Shaft Length: Approximately 1 7/8" Shaft Diameter:5/8" Mounting Type: Base-Mounted（Removable Base） Package Includes: 1*3 Phase Electric Motor
